CPU / Memory: Single-Core Cortex A7 @ 1.2 Ghz Processor (Allwinner V833 SoC) /2Gbit DDR3 SDRAM (Samsung 256MB DDR3 x 1pcs).
Recording resolution/Frame (FPS): Front: 1080P (1920x1080P), Max 30 frame, angle view 1 /Rear 720P (1280x720P), Max 30 frame
Angle view: Front 150 degrees/Rear 140 degrees.
Image Sensor: Front: Full HD CMOS Sensor
Rear: HD CMOS Sensor
Audio input: Built-in Microphone
Video Output: LCD and Mobile phone is connected with a dash cam via Wi-Fi dongle.
Video / Audio compression: H.264 / ADPCM
Resolution: Front Cam 1080P (1920x1080P), Rear Cam 720P(1280x720P)
Recording Time (Approx): All cameras: Max. 30FPS
Wi-Fi (Optional): Connect to GNET Smart phone application via Wi-Fi dongle.
G-Sensor: Event recording by External Shock.
Speaker: Operation Status alarm / Voice guidance
External GPS: Sync with Google map, keep track of location and Speed.
Viewer: Windows 7/8/10, Mac, Support 32Bit/64Bit, synchronizing Google map with PC viewer is supported for Windows7 and
explorer 10 as per Google’s policy
Power: DC 12V – 24V
Allowable current of providing fuse: 3A
Operation Temperature: -100C – 700C
Humidity: 10-95%
Dimension (WxHxD, mm): Front: 98x61.5x32, Rear 45x28x28
Cable for rear camera: TechPoint TV1 Type 3 wire cable (Basic length 6M).
ADAS: LDWS, FCWS, FVDW
Night vision: Ultra X vision
Time Lapse: Support: Record at 1fps when parking and save at 10fps from 2 seconds before an event occurs.
App via Wi-Fi dongle: Wi-Fi Dongle Type: Smartphone playback and settings, automatic firmware upgrade.
What's in the box?
-Front & Rear Camera
-Hardware Kit (Direct Power Cable & Rear Camera Connection Cable)
-Micro SD Card 32 GB
-User Manual
